1. Laser Specifications:

• Laser Type: Sealed Glass CO2 Laser Tube, emitting at a wavelength of 10-6 μm.
• Power Options: Available in multiple power ratings, including 80W, 100W, 120W, 150W, 180W, 200W, and 300W, allowing for flexibility based on material thickness and type.

2. Performance:

• Cutting Speed: Capable of cutting at speeds up to 40,000 mm/min.
• Engraving Speed: Engraving can be performed at speeds of up to 60,000 mm/min.
• Precision: Highest scanning precision is rated at 4000 DPI with a locating accuracy of ≤0.01 mm.

3. Working Area:

• Dimensions: The machine features a working area of 1600 mm x 1000 mm, suitable for large materials.
• Table Design: Equipped with a through table design allowing for processing of long materials without the need for repositioning.

4. Control and Software:

• Control System: Utilizes a DSP control system for enhanced operation.
• Software Compatibility: Supports various graphic formats (e.g., DST, PLT, BMP, DWG, DXF) and is compatible with software such as CorelDRAW, Photoshop, AutoCAD, and LightBurn.

5. Cooling and Safety Features:

• Cooling System: Water cooling system to maintain optimal operating temperatures.
• Safety Features: Includes an emergency stop button and auto-shutdown capabilities if safety conditions are compromised (e.g., water cooling failure).

6. Additional Functionalities:

• Auto-Focus and Red Dot Pointer: Facilitates precise cutting and engraving.
• Air Assist System: Helps in reducing burning of materials during the cutting process by blowing air onto the workpiece.
• Exhaust System: Ensures that smoke and fumes are effectively removed from the working area.

7. Build Quality:

• Drive System: High-precision three-phase stepper motor provides reliable movement and positioning.
• Robust Frame: Designed to minimize wobbling during high-speed operations.

8. Environmental Conditions:

• Operating Environment: Functions optimally within a temperature range of 0-45°C and humidity levels of 5-95% (non-condensing).
